Introduction to Processes

  • An executing program or job

  • Components

    • Memory address space

    • Program image

    • Handles to files

    • Interprocess communication

  • Every process has a parent

    • top most process in UNIX is “init”

    • Windows top most processes are:

      • system.exe - OS kernel

      • csrss.exe - handles user mode win32 calls

      • wininit.exe - manages system services

      • explorer.exe - OS shell

      • winlogin.exe - OS login service

Process Memory Layout

  • Text - machine instructions of a program.

  • Data - initialized static data and constants

  • BSS - uninitialized static data

  • Heap - dynamic memory of a process

    • one or more per process

  • Stack - local variables, call stack, return values

    • one per thread for kernel mode threads

    • one per n-threads for user mode threads

  • layout of and allocation of text, data, bss, and initial values for first thread’s stack and heap are the responsibility of the loader

  • management of stack and heap are through the process’s runtime library and program instructions

Process Memory Layout

Memory Layout

Memory Layout

Multithreaded Memory Layout

Memory Layout for Multithreaded Programs

Memory Layout for Multithreaded Programs

Preliminaries

  • Code for examples in maintained at https://github.com/gkthiruvathukal/systems-code-examples

  • You can use git clone https://github.com/gkthiruvathukal/systems-code-examples to clone to a folder systems-code-examples.

  • All subsequent examples that are full-working demonstrations will be referenced as systems-code-examples/<example-name>.

  • To run examples, make sure you have gcc, cmake, and make on your computer.

  • We only have tested on Ubuntu Linux, MacOS, and Windows Subsystem for Linux 2 (with Ubuntu 20.04 LTS). Most others should work.

Examine Process Layout Example

  • Most of our examples are written in C with some C++.

  • Getting the code

    git clone https://github.com/gkthiruvathukal/systems-code-examples cd systems-code-examples/c_intro

  • Generate the Makefile using cmake:

    $ cd c_intro
    $ cmake .
    -- The C compiler identification is GNU 9.3.0
    -- The CXX compiler identification is GNU 9.3.0
    -- Check for working C compiler: /usr/bin/cc
    -- Check for working C compiler: /usr/bin/cc -- works
    -- Detecting C compiler ABI info
    -- Detecting C compiler ABI info - done
    -- Detecting C compile features
    -- Detecting C compile features - done
    -- Check for working CXX compiler: /usr/bin/c++
    -- Check for working CXX compiler: /usr/bin/c++ -- works
    -- Detecting CXX compiler ABI info
    -- Detecting CXX compiler ABI info - done
    -- Detecting CXX compile features
    -- Detecting CXX compile features - done
    >> Linux
    -- Configuring done
    -- Generating done
    -- Build files have been written to: /home/gkt/Work/systems-code-examples/c_intro

  • Run make to crate the executable:

    $ make
    Scanning dependencies of target c-intro-demo
    [ 20%] Building CXX object CMakeFiles/c-intro-demo.dir/main.cc.o
    [ 40%] Building CXX object CMakeFiles/c-intro-demo.dir/debug.cc.o
    [ 60%] Building CXX object CMakeFiles/c-intro-demo.dir/list.cc.o
    [ 80%] Building CXX object CMakeFiles/c-intro-demo.dir/tests.cc.o
    [100%] Linking CXX executable bin/c-intro-demo
    [100%] Built target c-intro-demo

  • Note that for all of our examples, the output executable appears in the bin subdirectory.

  • Note also that almost all of our examples use cmake and make as shown here.

  • Run the layout shell script, which shows the size of the text, data, and bss in bytes:

    $ ./layout

    section               size   addr
    .text                 3957    4352
    .data                   24   20480
    .bss                     8   20504


Loading Programs

  • loader allocates memory for executable’s text, data, bss, heap, and stack. and loads program’s image into memory

  • loader gets information from OS where shared libraries are already allocated in memory and loads the ones that are not already loaded. each shared library has its own text, data, and bss

  • loader goes through executable and adjusts the list of external symbols to point to the correct spots in memory (to shared libraries)

  • try the nm command to see the symbols in a compiled object/executable.

  • once program is ready, loader invokes _start() method

  • _start() calls _init() for each shared library

  • _start() initializes static constructors of objects defined as global variables

  • _start() calls main() and program begins

Loading shared libraries (.so)

  • Libraries also have a data, bss, and text segment

  • Memory references in shared libraries are position independent (GCC -fpic or -fPIC flagsA. Newer GCC makes PIC defualt. Use -fno-pic if you notice this.

  • Linker must resolve all of these position independent memory accesses to local accesses. This is accomplished by writing the GOT for each linked process.

  • The need for the memory addresses to be position independent is because the offset that a shared library will be loaded will differ between executions of the same program and among other programs.

  • Also, the same loaded shared library will be shared with other processes without reloading. So, the same library may have different offsets for different programs

more about GCC pic option

Based on the man page for gcc

Generate position-independent code (PIC) suitable for use in a shared library, if supported for the target machine. Such code accesses all constant addresses through a global offset table (GOT). The dynamic loader resolves the GOT entries when the program starts (the dynamic loader is not part of GCC; it is part of the operating system). If the GOT size for the linked executable exceeds a machine-specific maximum size, you get an error message from the linker indicating that -fpic does not work; in that case, recompile with -fPIC instead. (These maximums are 8k on the SPARC and 32k on the m68k and RS/6000. The 386 has no such limit.)

Loading shared libraries (.so)

  • Static libraries do not contain position independent code

  • Static libraries are simply a collection of unlinked .o (object) files

  • The dynamic linker simply loads the text, data, and bss sections of each object file into the program’s address space

Position Independent Code Example

  • Get the code

    git clone https://github.com/gkthiruvathukal/systems-code-examples

    cd systems-code-examples/pic

  • For this example, you can build it using make -f Makefile.pic.

  • The main purpose of this example is to show the difference between generating PIC vs. non-PIC.

main.cc

 1#include <unistd.h>
 2
 3const char *msg = "abcdefg";
 4
 5int main(int argc, char* argv[])
 6{
 7
 8    const char *x = msg + 1;
 9
10    write(1, x, 1);
11
12    return (0);
13
14}
15

main.nopic.s - non-position independent code (gcc -fno-pic)

 1	.file	"main.c"
 2	.text
 3	.globl	msg
 4	.section	.rodata
 5.LC0:
 6	.string	"abcdefg"
 7	.data
 8	.align 8
 9	.type	msg, @object
10	.size	msg, 8
11msg:
12	.quad	.LC0
13	.text
14	.globl	main
15	.type	main, @function
16main:
17.LFB0:
18	.cfi_startproc
19	endbr64
20	pushq	%rbp
21	.cfi_def_cfa_offset 16
22	.cfi_offset 6, -16
23	movq	%rsp, %rbp
24	.cfi_def_cfa_register 6
25	subq	$32, %rsp
26	movl	%edi, -20(%rbp)
27	movq	%rsi, -32(%rbp)
28	movq	msg(%rip), %rax
29	addq	$1, %rax
30	movq	%rax, -8(%rbp)
31	movq	-8(%rbp), %rax
32	movl	$1, %edx
33	movq	%rax, %rsi
34	movl	$1, %edi
35	call	write
36	movl	$0, %eax
37	leave
38	.cfi_def_cfa 7, 8
39	ret

main.nopic.s - position independent code (gcc -fpic, default option)

 1	.file	"main.c"
 2	.text
 3	.globl	msg
 4	.section	.rodata
 5.LC0:
 6	.string	"abcdefg"
 7	.section	.data.rel.local,"aw"
 8	.align 8
 9	.type	msg, @object
10	.size	msg, 8
11msg:
12	.quad	.LC0
13	.text
14	.globl	main
15	.type	main, @function
16main:
17.LFB0:
18	.cfi_startproc
19	endbr64
20	pushq	%rbp
21	.cfi_def_cfa_offset 16
22	.cfi_offset 6, -16
23	movq	%rsp, %rbp
24	.cfi_def_cfa_register 6
25	subq	$32, %rsp
26	movl	%edi, -20(%rbp)
27	movq	%rsi, -32(%rbp)
28	movq	msg@GOTPCREL(%rip), %rax
29	movq	(%rax), %rax
30	addq	$1, %rax
31	movq	%rax, -8(%rbp)
32	movq	-8(%rbp), %rax
33	movl	$1, %edx
34	movq	%rax, %rsi
35	movl	$1, %edi
36	call	write@PLT
37	movl	$0, %eax
38	leave
39	.cfi_def_cfa 7, 8
40	ret

What’s the difference?

 1diff main.pic.s main.nopic.s
 27c7
 3< 	.section	.data.rel.local,"aw"
 4---
 5> 	.data
 628,29c28
 7< 	movq	msg@GOTPCREL(%rip), %rax
 8< 	movq	(%rax), %rax
 9---
10> 	movq	msg(%rip), %rax
1136c35
12< 	call	write@PLT
13---
14> 	call	write

Shared Libraries - Evaluation

Strengths

  • Reduced memory footprint. If two programs load the same shared library, the .text segment is reused across processes thanks to the GOT

Weaknesses

  • Requires a more advanced virtual memory implementation in the operating system. Sometimes not practical for simple or embedded systems

  • Requires more advanced compiler code generators. Different processors have special features regarding memory offset registers or function table size limitations.

Static Libraries - Evaluation

Strengths

  • Makes sense when re-use is not desired. A good example would be installer executables with very large .data segments.

  • Faster first load loading time than shared libraries.

  • Fewer instructions generated for GOT lookups (minor issue)

Weaknesses

  • Much larger memory footprint. Little reuse of common code between applications.

Libraries vs. Statically-Linked Programs

Dynamic Linking advantages:

  • Memory footprint

  • Code reuse

  • Improvement with new versions of shared libraries

  • Smaller executables

Static linking advantages:

  • When deploying software, dependencies are less of a concern (e.g. missing dependencies, incorrectly upgraded dependencies, custom patches and alterations to shared code)

  • Versioning and path problems are less of a concern

  • Code obfuscation can obfuscate across object files

  • Compiler optimizers can optimize across object files

Process Protection

In modern operating systems with virtual memory and privileged separation the following protections are afforded:

  • One process cannot read the memory of another process (except when explicitly permitted)

  • A process can fully manage the memory that it can access - garbage collection, explicit allocation/deallocation, method call and parameter passing standards, stack management, etc.

  • A crash, exception, resource starvation, deadlock, or other fault in one process does not directly affect other processes

  • While mapped to the same address space, the process cannot modify kernel memory or memory otherwise protected by the operating system (such as text pages).

Process Creation with fork()

From the fork() man page:

  • fork() creates a new process by duplicating the calling process. The new process, referred to as the child, is an exact duplicate of the calling process, referred to as the parent, except for the following points:

  • the child has its own unique process id (PID)

  • the child’s parent PID is the same as the parent’s PID

  • the parent’s threads are not recreated on the child

interesting point: in Linux, fork() != fork(); fork() calls clone()

From the man page:

  • fork() returns the child PID to the parent

  • fork() returns 0 to the child

  • fork() returns -1 if the child cannot be created

fork() example

See systems-code-examples/fork if you want to run this program.

$ cd systems-code-examples/fork
$ cmake
$ make
 1#include <stdio.h>
 2#include <unistd.h>
 3#include <fcntl.h>
 4#include <string.h>
 5
 6int main(int argc, char* argv[])
 7{
 8    int SomeValue = 100;
 9    int pid = fork();
10    int fd = open("test_file", O_WRONLY|O_CREAT|O_TRUNC, 0666);
11
12    const char *parentMessage = "1111111";
13    const char *childMessage =  "22222222222222\n";
14
15    if(pid > 0)
16    {
17        printf("hello from the parent process, chid pid = %d\n", pid);
18        sleep(2);
19        printf("parent's SomeValue = %d\n", SomeValue);
20        write(fd, parentMessage, strlen(parentMessage) * sizeof(char));
21    }
22    else if(pid == 0)
23    {
24        printf("hello from the child process\n");
25        SomeValue = 200;
26        printf("child's SomeValue = %d\n", SomeValue);
27        write(fd, childMessage, strlen(childMessage) * sizeof(char));
28    }
29    else
30    {
31        printf("fork() failed!!\n");
32    }
33
34    close(fd);
35
36    return 0;
37}
38
39

Process Creation with clone()

  • similar to fork() in that a child process is created.

  • clone() allows different parts of the parent process to be shared with the child process

  • flags for creating a light weight process (kernel thread):

    • CLONE_FS - share FS information (chroot, chdir, umask)

    • CLONE_FILES - share file descriptor table

    • CLONE_SIGHAND - share signal handlers

    • CLONE_VM - share page table

  • many more flags exist - don’t forget this little known capability!

  • glibc’s version of fork(), calls clone() without any of these flags

  • clone() not present in every UNIX OS (available in Linux but not Minix)

Windows CreateProcess() and CreateThread()

  • Different from UNIX fork()/clone() - parts of processes are not shared

  • Windows has two flavors:

    • CreateProcess() - creates a new process, equivalent of calling fork() then execve() in UNIX

    • CreateThread() - equivalent of creating clone() with thread flags

  • Is this a disadvantage?

    • For most use cases and most programs, no.

    • The vast majority of calls to clone() in UNIX are equivalent to CreateThread()

    • The vast majority of calls to fork() in UNIX are equivalent to CreateProcess()

Emulating fork() on Windows

A well known system, Cygwin, implements fork() on Windows as follows:

  1. cygwin.dll calls CreateProcess() to create a suspended child process

  2. parent process calls setjmp() to save registers

  3. parent process copies its BSS and DATA sections to the child’s address space.

  4. parent wakes child up and waits on a named mutex (mutual exclusion mechanism).

  5. child wakes up, realizes it was a forked process, then longjumps to the saved jump buffer. child unlock’s

  6. parent’s named mutex and waits on a second mutex

  7. parent wakes up, copies its stack and heap to the child process. release’s child’s named mutex

  8. Child wakes up and copies any memory mapped regions the parent signals to the child through shared memory

  9. fork() system call in Cygwin does not use copy on write, but “copy on fork”. this is similar to fork() implementations in early UNIX operating systems

Causes of process termination

  • Normal exit–return from main(...)

  • Error exit–return from main(...) with an error code

  • Fatal error

    • segfault/bus error–process tries to read/write inaccessible memory or write to read-only memory.

    • stack overflow–stack pointer grows to larger than stack area

    • protection fault–trying to run privileged instructions such as enabling/disabling interrupts

    • instruction faults–divide by zero

  • External termination by another process either through signals or system calls

wait() and waitpid() examples

See systems-code-examples/wait if you want to run this program.

 1#include <sys/types.h>
 2#include <sys/wait.h>
 3#include <stdio.h>
 4#include <stdlib.h>
 5#include <unistd.h>
 6
 7
 8int main(int argc, char* argv[])
 9{
10    pid_t pid = fork();
11    if(pid == 0)
12    {
13        abort();    //child process exits
14    }
15    int status;
16    wait(&status); // wait for child to exit
17    if(WIFEXITED(status))
18    {
19        printf("normal exit. exit code = %d\n", WEXITSTATUS(status));
20    }
21    else if(WIFSIGNALED(status))
22    {
23        printf("abnormal termination, signal number = %d\n", WTERMSIG(status));
24    }
25    else if(WIFSTOPPED(status))
26    {
27        printf("child stopped, signal number = %d\n", WSTOPSIG(status));
28    }
29}
30
31
